Clinical workflow integration, diagnostic efficacy, and device utility
The DHPT-1150 Emergency & Recovery Hydraulic Patient Transfer Trolley is a heavy-duty hospital transport stretcher engineered for emergency trauma rooms, recovery bays, and post-operative surgical transit in India. Powered by dual foot-operated hydraulic pedals, healthcare staff can elevate, lower, and tilt the stretcher into Trendelenburg positions effortlessly without interrupting patient monitoring. Built on a rigid epoxy powder-coated mild steel framework, it incorporates collapsible stainless steel safety side rails, a built-in oxygen cylinder cage, full-length X-ray cassette sliding track, and steering-guided castors with central braking. Supplied by SMD Medicare with wholesale institutional pricing and prompt pan-India logistics.
Core technical and clinical performance highlights
Safe Working Load (SWL) of 250 kg, uniformly distributed.
Hydraulic height adjustment mechanism, providing a vertical range of 550mm to 850mm from the floor to the patient platform.
Patient surface composed of an 80mm high-density foam mattress, encased in a fire-retardant, anti-bacterial, fluid-resistant polyurethane cover.
Equipped with four 200mm anti-static swivel castors, featuring a central braking system and an additional directional lock castor.
Integrated two-section aluminum drop-down side rails, actuated by a positive locking and quick-release mechanism.
Backrest adjustable from 0° to 70° and Trendelenburg/Reverse Trendelenburg positions adjustable to ±12°, both via gas spring assist.
Frame constructed from electrostatically powder-coated mild steel, incorporating an oxygen cylinder holder and an undercarriage utility tray.
Official OEM technical parameters and procurement specifications
| Product SKU / Code | SMD-206 |
|---|---|
| Brand / Manufacturer | |
| Medical Category | Hospital Furniture (Stretcher) |
| Packaging | 1 unit |
| Warranty | 1 Year |
| Material | High-grade mild steel / Stainless steel framework |
| Finish | Epoxy powder coated for rust resistance and easy cleaning |
| Top Surface | Radiolucent / ABS / Stainless Steel (model specific) |
| Mobility | Heavy-duty non-marking castors with diagonal locking brakes |
| Height Adjustment | Hydraulic / Electro-mechanical mechanism |
| Positions | Trendelenburg, Reverse Trendelenburg, Lateral Tilt, Backrest elevation |
| Weight Capacity | Supports safe working load up to 250 kg |
| Mattress | High-density foam with water-resistant, anti-static cover |
| Side Rails | Collapsible safety side rails (ABS or aluminum) |
| Accessories | IV Pole, Monitor Tray, Oxygen Cylinder Holder |
| Base | Stable base design with protective bumpers |
| Control | Wired remote control / Foot pedal (for electric/hydraulic models) |
| Safety | Manual CPR release mechanism |
| Dimensions | Standard hospital dimensions (L x W x H adjustable) |
| Compliance | Manufactured as per international hospital furniture standards |
Standard operating guidance for biomedical technicians and clinical staff
Are you a healthcare professional or hospital staff using this device? Share your clinical experience.
Key hospital procurement terms regarding warranty, pan-India logistics, GST billing, clinical calibration, and bulk contracts
All genuine Patients Transfer Trolly units carry official 1 to 2 Years OEM Manufacturer Warranty covering manufacturing defects and biomedical engineering evaluation. Dedicated technical support and repair assistance are provided across India and international client destinations.
We use damage-proof wooden crate packaging with internal foam cushioning for both domestic freight and global air/sea cargo. Shipments are delivered across all Indian states in 3 to 7 business days with transit insurance, while international export orders (USA, UK, Europe, UAE, Asia) include export documentation, customs clearance, and global consignment tracking.
Yes, 100% compliant GST tax invoices with certified HSN codes are issued for every order. Hospitals, registered medical institutions, and equipment dealers can claim full Input Tax Credit (ITC) on their purchases.
We supply pre-installation civil and electrical checklists, user operating manuals, and video/on-site biomedical engineer guidance. Our certified engineers ensure proper calibration and operational testing before clinical handover.
Yes, SMD Medicare offers special institutional pricing, volume tender rates, and turnkey OT/ICU packages for hospitals, diagnostic centers, and medical supply dealers. You can request a tailored commercial proforma quotation directly.
Yes, authentic OEM spare parts, specialized accessories, and post-warranty Annual Maintenance Contracts (AMC) and Comprehensive Maintenance Contracts (CMC) are available to ensure zero clinical downtime.
