The 300mA X-Ray Machine with Floating Top Table is an ergonomic diagnostic solution designed for rapid, strain-free patient positioning in high-volume hospital trauma centers, orthopedics, and surgical facilities. Featuring a heavy-duty 4-way floating tabletop with silent electromagnetic foot-pedal brakes, this system allows technicians to center complex trauma patients without requiring physical patient repositioning.
Includes complete site inspection, room shielding verification, equipment delivery, on-site commissioning by factory-trained biomedical engineers, AERB e-LORA portal documentation support, and a comprehensive 12-month warranty with guaranteed spare parts availability.
Core technical and clinical performance highlights
High-frequency X-ray generator with a maximum output of 300m A and a 40-125 k Vp range.
Dual focal spot X-ray tube (e.g., 0.8/1.5 mm) for varying resolution requirements in radiography.
Exposure time settings configurable from 0.001 seconds to 6.3 seconds, with m As range of 1-300 m As.
Floating tabletop design offering longitudinal and transverse movement with electromagnetic braking for precise patient positioning.
Tabletop constructed from low-attenuation carbon fiber or phenolic resin to minimize X-ray dose to the patient.
Integrated oscillating Bucky device, typically featuring a 103 L/inch, 8:1 ratio grid for enhanced image contrast.
Manual multi-leaf light beam collimator with field rotation for accurate beam limitation.
Microprocessor-controlled operational console with digital display for k Vp, m A, and m As parameters.
Official OEM technical parameters and procurement specifications
| Product SKU / Code | SMD-30260 |
|---|---|
| Brand / Manufacturer | |
| Medical Category | Hospital Equipment (X-Ray Machines) |
| Model Type | 300mA X-Ray Suite with 4-Way Floating Top Table |
| Generator Power | 30 kW High-Frequency Inverter (40 kHz, Microcontroller Console) |
| Output Stations | 50, 100, 150, 200, 300 mA |
| kVp Range | 40 kVp to 125 kVp (1 kVp incremental adjustments) |
| mAs Range | 0.1 to 300 mAs across 32 steps |
| Tabletop Dimensions | 2,000 mm length x 750 mm width x 750 mm height |
| Tabletop Movement | 4-Way Float: Longitudinal travel ±450 mm, Transverse travel ±120 mm |
| Tabletop Locking | Electromagnetic brakes with full-length foot-switch release |
| Patient Weight Capacity | 220 kg (485 lbs) maximum load rating |
| X-Ray Tube | Rotating Anode with dual focal spots (1.0 mm / 2.0 mm) |
| Anode Thermal Rating | 140 kHU with thermal cut-off sensor |
| Bucky Movement | Motorized oscillating bucky with 85 L/inch, 8:1 ratio grid |
| Cassette Compatibility | Supports 8x10 to 14x17 inch Darkroom, CR and Wireless DR Detectors |
| Collimator | Multi-leaf manual collimator with LED centering light field |
| AERB Compliance | Type Approved under AERB/SC/MED-2 guidelines |
| Power Supply | 415V AC, 3-Phase, 50 Hz (30 kVA line capacity) |
| Certifications | AERB Approved, ISO 13485:2016, CE Certified |
Are you a healthcare professional or hospital staff using this device? Share your clinical experience.
Key hospital procurement terms regarding warranty, pan-India logistics, GST billing, clinical calibration, and bulk contracts
All genuine 300mA X-Ray Machine with Floating Top Table units carry official 1 to 2 Years OEM Manufacturer Warranty covering manufacturing defects and biomedical engineering evaluation. Dedicated technical support and repair assistance are provided across India and international client destinations.
We use damage-proof wooden crate packaging with internal foam cushioning for both domestic freight and global air/sea cargo. Shipments are delivered across all Indian states in 3 to 7 business days with transit insurance, while international export orders (USA, UK, Europe, UAE, Asia) include export documentation, customs clearance, and global consignment tracking.
Yes, 100% compliant GST tax invoices with certified HSN codes are issued for every order. Hospitals, registered medical institutions, and equipment dealers can claim full Input Tax Credit (ITC) on their purchases.
We supply pre-installation civil and electrical checklists, user operating manuals, and video/on-site biomedical engineer guidance. Our certified engineers ensure proper calibration and operational testing before clinical handover.
Yes, SMD Medicare offers special institutional pricing, volume tender rates, and turnkey OT/ICU packages for hospitals, diagnostic centers, and medical supply dealers. You can request a tailored commercial proforma quotation directly.
Yes, authentic OEM spare parts, specialized accessories, and post-warranty Annual Maintenance Contracts (AMC) and Comprehensive Maintenance Contracts (CMC) are available to ensure zero clinical downtime.
